Product Description
Technical Requirements:
Material: AL-99.5%
Surface treatment: Bright
Products property: It is used to connect the aluminum conductor end.
Technical Parameter
|
Type no |
Dimension(mm) |
|||||
|
Φ |
D |
d |
L |
L1 |
A |
|
|
DL-10 |
8.5 |
9 |
5.3 |
64 |
29 |
16 |
|
DL-16 |
8.5 |
10 |
6.3 |
67 |
31 |
16 |
|
DL-25 |
8.5 |
15 |
7.3 |
75 |
34 |
18 |
|
DL-35 |
10.5 |
14 |
8.5 |
85 |
40 |
20.5 |
|
DL-50 |
10.5 |
16 |
9.8 |
90 |
42 |
23 |
|
DL-70 |
12.5 |
18 |
11.5 |
102 |
48 |
26 |
|
DL-95 |
12.5 |
21 |
13.5 |
112 |
52 |
28 |
|
DL-120 |
14.5 |
23 |
15.0 |
120 |
53 |
30 |
|
DL-150 |
14.5 |
25 |
16.5 |
126 |
56 |
34 |
|
DL-185 |
17 |
27 |
18.5 |
133 |
58 |
37 |
|
DL-240 |
17 |
30 |
21.0 |
140 |
60 |
40 |
|
DL-300 |
21 |
34 |
24.0 |
160 |
65 |
50 |
|
DL-400 |
21 |
38 |
27.0 |
170 |
70 |
50 |
|
DL-500 |
21 |
42 |
29.0 |
188 |
75 |
60 |
