Specifications:

Mounting Instruction of Crossing Bus-bar Fittings

In order to meet the installation needs, please provide the size shown below and the following information when ordering:

1. Wiring direction of the transformer terminal plate  (horizontal, vertical)

2. Transformer terminal plate  size (length a x width b)

3. Transformer terminal plate material (copper or aluminum)

4. Wiring direction of the terminal plate of the circuit breaker (horizontal, vertical and horizontal reverse angle)

5. Circuit breaker terminal plate size (length a x width b)

6. Circuit breaker terminal plate material (copper or aluminum)

If the crossing bus-bar is required to be horizontally arranged, please provide the accurate ground clearance of the transformer and circuit breaker terminal block.

Dimensions:

(1) Connection plate with current transformer

(2) Tube bus-bar connection fitting

(3) Expansion joint

(4) Circuit breaker terminal block
