Classification：Station Fittings
Inside Road & Administration Industry & Trading Garden,Houshan Industry Area,Fuzhou City,Fujian Province
0591-22806687 0591-22806697
0591-22806667
Specifications:
|
Type |
Application bus specification |
Main Dimensions (mm) |
||
|
Φ1 |
D |
L1 |
||
|
MTLY-70-400A |
Φ 70/64 |
70 |
55 |
120 |
|
MTLY-80-400A |
Φ 80/72 |
80 |
55 |
120 |
|
MTLY-85-400A |
Φ 85/75 |
85 |
55 |
120 |
|
MTLY-90-400A |
Φ 90/80 |
90 |
55 |
120 |
|
MTLY-100-400A |
Φ 100/90 |
100 |
55 |
120 |
|
MTLY-100-800A |
Φ 100/90 |
100 |
72 |
170 |
|
MTLY-110-400A |
Φ 110/100 |
110 |
55 |
120 |
|
MTLY-120-400A |
Φ 120/110 |
120 |
55 |
120 |
|
MTLY-130-185A |
Φ 130/116 |
130 |
36 |
90 |
|
MTLY-130-400A |
Φ 130/116 |
130 |
55 |
120 |
|
MTLY-130-1440A |
Φ 130/116 |
130 |
80 |
240 |
|
MTLY-150-400A |
Φ 150/136 |
150 |
55 |
120 |
|
MTLY-170-400A |
Φ 170/156 |
170 |
55 |
120 |
|
MTLY-200-400A |
Φ 200/180 |
200 |
55 |
120 |
|
MTLY-200-630A |
Φ 200/180 |
200 |
70 |
150 |
Notes:
The main body and gland are made of aluminum, and the rest are hot-dip galvanized steel parts.
① is a casting, ② is a squeezed aluminum tube, and ① and ② are welded
According to the needs of users, please specify the wire type when ordering.
