Classification：Station Fittings
Inside Road & Administration Industry & Trading Garden,Houshan Industry Area,Fuzhou City,Fujian Province
0591-22806687 0591-22806697
0591-22806667
Specifications 1:
|
Type |
Application bus specification |
Main Dimensions (mm) |
||||
|
Φ |
H |
H1 |
D |
M |
||
|
MGD-50 |
Φ 50/45 |
50 |
80 |
40 |
140 |
12 |
|
MGD-60 |
Φ 60/54 |
60 |
90 |
40 |
140 |
12 |
|
MGD-70 |
Φ 70/64 |
70 |
90 |
40 |
140 |
12 |
|
MGD-80 |
Φ 80/72 |
80 |
98 |
40 |
140 |
12 |
|
MGD-85 |
Φ 85/75 |
85 |
100 |
40 |
140 |
12 |
|
MGD-90 |
Φ 90/80 |
90 |
102 |
40 |
140 |
12 |
|
MGD-100 |
Φ 100/90 |
100 |
114 |
40 |
140 |
12 |
|
MGD-100(225) |
Φ 100/90 |
100 |
114 |
40 |
225 |
16 |
|
MGD-110(225) |
Φ 110/100 |
110 |
120 |
45 |
225 |
16 |
|
MGD-120(225) |
Φ 120/110 |
120 |
122 |
45 |
225 |
16 |
|
MGD-130(225) |
Φ 130/116 |
130 |
135 |
50 |
225 |
16 |
|
MGD-150(225) |
Φ 150/136 |
150 |
150 |
50 |
225 |
16 |
Notes:
The main body and gland are made of aluminum, and the rest are made of hot-dip galvanized steel.
If the hole distance of the supporting post insulators required by the user is different from the above, please specify the order.
