Classification：Cable Fittings
Inside Road & Administration Industry & Trading Garden,Houshan Industry Area,Fuzhou City,Fujian Province
0591-22806687 0591-22806697
0591-22806667
Technical Requirements
Technical Parameters
|
Type no |
Dimension(mm) |
Remark |
|||||
|
d |
D |
L |
L1 |
A |
Φ |
||
|
CAL-16B |
5.5 |
16 |
85 |
43 |
21 |
10.5 |
FIG 1 |
|
CAL-25B |
6.5 |
16 |
85 |
43 |
21 |
10.5 |
|
|
CAL-35B |
8.0 |
16 |
85 |
43 |
21 |
10.5 |
|
|
CAL-50B |
9.0 |
20 |
90 |
43 |
25.6 |
12.8 |
|
|
CAL-70B |
11.0 |
20 |
90 |
43 |
25.6 |
12.8 |
|
|
CAL-95B |
12.5 |
20 |
90 |
43 |
25.6 |
12.8 |
|
|
CAL-120B |
13.7 |
25 |
115 |
59 |
25.6 |
12.8 |
|
|
CAL-150B |
15.5 |
25 |
115 |
59 |
30 |
12.8 |
|
|
CAL-185B |
17.0 |
32 |
115 |
59 |
30 |
12.8 |
|
|
CAL-240B |
19.5 |
32 |
115 |
59 |
30 |
12.8 |
|
|
CAL-300B |
23.3 |
40 |
160 |
93 |
35 |
16.5 |
|
|
CAL-400B |
26.0 |
40 |
160 |
93 |
35 |
16.5 |
|
|
CAL-500B |
29.1 |
47 |
200 |
94 |
60 |
16.5 |
FIG 2 |
|
CAL-630B |
32.5 |
47 |
200 |
94 |
60 |
16.5 |
|
